PRODUCT DESCRIPTION

Barbed wire is the most popular fencing wire made in three processing methods: traditional twisted, positive / straight twisted, reverse / negative twisted. Strands can be single or double. The wires are braided with a system of constant torsion, with barb prongs interlaced in the wires. As a traditional fencing product for protection and privacy, barbed wire is widely used in civil and military life.


Wire Materials: Galvanized steel wire, PVC coated iron wire in blue, green, yellow and other colors.


General Use: Barbed wire mainly serves in protecting of grass boundary, railway, highway, etc.



Customized Specifications


Barbed wire: 12x12 in BWG, Barb spacing: 6.0617 mm


barbed wire 2.5 mm, barbed length :20 mm double strand

4 points barbs at every 75mm


Barbed wires
Mat STEEL
Mat, spec ASTM A121
Diameter 2.5 mm
Number, barb points 4
Distance, between barbs 75 mm
Length 200 m
Coating GALVANIZED


galvanized barbed wire,
iowa pattern, 2 ply, 4 points,
galvanised mild steel, 2.5 mm, spacing between barbs 101 mm
supplied in reels of 200 meters each, 2 mm



iowa pattern, 2 ply, 4 points.
galvanized strand wire 2.50mm dia galvanized
barbing wire 2.0 mm, spacing between barbs 101 mm supplied in reels of 200 meters each.


Gauge of
Strand and Barb in B.W.G.
Approximate Length per Kilo in Meter
Barbs Spacing 3"
Barbs Spacing 4"
Barbs Spacing 5"
Barbs Spacing 6"
12x12
6.0617
6.7590
7.2700
7.6376
12x14
7.3335
7.9051
8.3015
8.5741
12-1/2x12-1/2
6.9223
7.7190
8.3022
8.7221
12-1/2x14
8.1096
8.814
9.2242
9.5620
13x13
7.9808
8.899
9.5721
10.0553
13x14
8.8448
9.6899
10.2923
10.7146
13-1/2x14
9.6079
10.6134
11.4705
11.8553
14x14
10.4569
11.6590
12.5423
13.1752
14-1/2x14-1/2
11.9875
13.3671
14.3781
15.1034
15x15
13.8927
15.4942
16.6666
17.5070
15-1/2x15-1/2
15.3491
17.1144
18.4060
19.3386
