Product Description

Tinplate coil is a thin gauge, cold reduced mild steel coil or strip coated on both sides with commercially pure tin. They combine the properties of steel and tin, combining the strength of steel with the corrosion resistance and solderability of tin.

Feature of tinplate coil :

1. Tinplate is light in weight and high in strength, making it easy to transport and store.
2 Tinplate is the best material to provide the best protection for food.
3 Tinplate provides a safe and reliable packaging option for chemical/technical products.




Specifications of tinplate coil

Size:

thickness: 0.15-0.5MM

width: 700-1100MM

Medium and high-grade food-grade tin-plated products, the main application fields include milk powder cans, ketchup cans, eight-treasure porridge cans, aerosol cans, top and bottom lids and various beverage cans.

The plate shape control technology can meet the requirements of the 80 sheets/minute printing production line; the thickness, hardness and tin plating uniformity control technology can meet the requirements of the 800 cans/minute high-speed can production line.


ITEMOnce rolled productSecondary rolled product
Cutting boardSteel coilCutting boardSteel coil
Manufacturable RangeUsual Manufacturable RangeManufacturable RangeUsual Manufacturable RangeManufacturable RangeUsual Manufacturable RangeManufacturable RangeUsual Manufacturable Range

0.15-0.500.18-0.400.15-0.800.18-0.600.135-0.360.135-0.360.135-0.360.135-0.36
Thickness(mm)

Width(mm)457-1,038508-970457-1,038508-970457-1,038508-1,038457-970508-965
Length(mm)480-1,100500-1,050480-1,100500-1,050
Weight(mm)2.0-10.03.0-10.02.0-10.03.0-10.0
Inner diameter(mm)419/508419/508419/508419/508
Outer diameter(mm)1,740Max1,740Max1,740Max1,740Max
Tin plating amount(g)1.1/1.1,2.8/2 8,5.6Z5.6,8.4Z8.4,11.2/11.2,19.0/19.0
1.1/2.8,2.8Z5.6,2.878.4,2.8/11.2 , 5.6Z8.4 , 5.6/11.2 , 5.6/15.1,8.4/11.2,8.4/15.1
AnnealingBA、CACA
SurfaceB、R1、R2、S1、S2、S3R1
HardnessT1、T2、T2.5、T3、T3.5、T4、T5DR7.5、DR8、DR9、DR9M、DR10
OiledDOS

Reflow, No reflow

Remarks: Usually manufacturing standard JISG3303, acceptable manufacturing standard ASTM, EN



Product Inventory

We are a professional tinplate dealer. With the support of the most professional tinplate manufacturers and a large number

of customers, we can not only provide you with ordinary tinplate but also help you find very personalized tinplate, such as

special tinplate grades, Special sizes, special craft shapes, etc.



Packaging And Shipping

We adopt standard export shipping packaging and bundles steel strips according to the size of the tinplate sheet. According

to our delivery experience, a 20-foot container can hold 22 tons of tinplate, and a 40-foot container can hold 25 tons of tinplate.

For larger orders, we use bulk vessels to transport you, and the price is cheaper. Also, we can customize the packaging according

to the needs customers.
