PRODUCT DETAILS


Product introduction


ERW Steel Pipe:

Pipe Type: ERW Pipe, ERW Steel Pipe, Electric Resistance Welded Pipe

Application: For Low Pressure Fluid Transmission, Machinery Manufacturing

Specification: OD: 21.3mm ~ 660mm

                          WT: 1mm ~ 17.5mm

                          LENGTH: 0.5mtr ~ 22mtr (5.8/6/11.8/12 meters, SRL, DRL)

Standard & Grade: API 5L PSL1/PSL2 Gr.A,Gr.B,X42,X46,X52,X56,X60,X65,X70
ASTM A53, ASTM A500, JIS G3466, ASTM A252, ASTM A178, AN/NZS 1163, AN/NZS 1074, EN10219-1, EN10217-1

End: Square Ends/Plain Ends (straight cut, saw cut, torch cut), Beveled/Threaded Ends

Surface: Bare, Lightly Oiled, Black/Red/Yellow Painting, Zinc/Anti-corrosive Coating

Packing: Bundled/In Bulk, Plastic Caps Plugged, Waterproof Paper Wrapped


Production Process for ERW steel pipe:

  1. Uncoiling --- 2. Leveling --- 3. End cutting --- 4. End shearing welding --- 5. Supercoil accumulator --- 6. Edge cutting --- 7. Ultrasonic detection --- 8. Forming --- 9. Electric induction welding --- 10. Ultrasonic detection for weld seam --- 11. Medium frequency heat treatment --- 12. Air cooling --- 13. Water cooling --- 14. Sizing --- 15. Flying cutting --- 16. Flush-out --- 17. Cropping --- 18. Flattening testing --- 19. Straightening --- 20. End facing and bevelling --- 21. Hydrodynamic testing --- 22. Ultrasonic detection for weld seam --- 23. Ultrasonic detection for pipe end --- 24. Visual and dimensions inspection --- 25.Weighting and measuring --- 26. Marking --- 27. Coating --- 28. Pipe-end protection --- 29. Bending --- 30. Shipping


Specification of ERW steel pipe:

API 5L/ASTM A53 GR.B (Small Diameter ERW Steel Pipe)

Outside Diameter

Wall Thickness

Outside Diameter

Wall Thickness

外径 (mm)

壁厚 (mm)

外径 (mm)

壁厚 (mm)

33.4
(1")

2.1-2.4

Φ133

3.0-5.75

2.5-3.25

6.0-7.75

3.5-4.0

8.0-10

42.3
(1.2")

2.1-2.4

Φ139.7
(5″)

3.0-4.5

2.5-3.5

4.75-5.75

3.75

6.0-7.75

4.0-5.0

8.0-10

48.3
(1.5")

2.1-2.4

Φ152

3.0-4.5

2.5-3.25

4.75-5.75

3.5-3.75

6.0-7.75

4.0-4.25

8.0-10.0

4.5-6.0

Φ159

3.25-6.75

Φ60.3
(2″)

3.0-4.0

6.8-7.75

4.25-4.75

8.0-10.0

5.0-5.75

10.0-11.75

Ф73

3.0-4.75

Φ165

3.0-6.0

4.8-5.25

6.25-7.0

5.5-7.0

/

Φ76.1





Warehouse Storage

with years of experience in competitive steel products at home and abroad, to provide reliable services to global customers.The main products are steel pipe, steel plate, steel coil, steel rod, steel strip, section steel, silicon steel, stainless steel series, carbon steel series, aluminum products and so on. Products are widely used in precision instruments, aviation, ships, automobiles, home appliances, construction, Bridges, boilers, highway guardrail and other industries.



Packing and shipping

Products are widely used in precision instruments, aviation, ships, automobiles, home appliances, construction, Bridges, boilers, highway guardrail and other industries. Annual sales of more than 6 million tons. Products are exported to more than 80 countries and regions. We have won the recognition of customers with good reputation and good service.



Application field

The company is located in Jinan City, Shandong Province, adjacent to Qingdao Port, Tianjin port, export traffic conditions are convenient.    The main products are steel pipe, steel plate, steel coil, steel strip, section steel, silicon steel, stainless steel series, carbon steel, galvanized color coating series, etc.    Products are widely used in precision instruments, aviation, ships, automobiles, medical, construction, Bridges, boilers, parts processing and other industries.
